This IBM Redbooks® publication covers IBM TS7700 R5.3. The IBM TS7700 is part of a family of IBM Enterprise tape products. This book is intended for system architects and storage administrators who want to integrate their storage systems for optimal operation. Building on over 25 years of experience, the R5.3 release includes many features that enable improved performance, usability, and security. Highlights include the IBM TS7700 Advanced Object Store, an all flash TS7770, grid resiliency enhancements, and Logical WORM retention. By using the same hierarchical storage techniques, the TS7700 (TS7770 and TS7760) can also off load to object storage. Because object storage is cloud-based and accessible from different regions, the TS7700 Cloud Storage Tier support essentially allows the cloud to be an extension of the grid. As of this writing, the TS7700C supports the ability to off load to IBM Cloud Object Storage, Amazon S3, and RSTOR. This publication explains features and concepts that are specific to the IBM TS7700 as of release R5.3. The R5.3 microcode level provides IBM TS7700 Cloud Storage Tier enhancements, IBM DS8000 Object Storage enhancements, Management Interface dual control security, and other smaller enhancements. The R5.3 microcode level can be installed on the IBM TS7770 and IBM TS7760 models only. TS7700 provides tape virtualization for the IBM Z® environment. Off loading to physical tape behind a TS7700 is used by hundreds of organizations around the world. New and existing capabilities of the TS7700 5.3 release includes the following highlights: Support for IBM TS1160 Tape Drives and JE/JM media Eight-way Grid Cloud, which consists of up to three generations of TS7700 Synchronous and asynchronous replication of virtual tape and TCT objects Grid access to all logical volume and object data independent of where it resides An all flash TS7770 option for improved performance Full Advanced Object Store Grid Cloud support of DS8000 Transparent Cloud Tier Full AES256 encryption for data that is in-flight and at-rest Tight integration with IBM Z and DFSMS policy management DS8000 Object Store with AES256 in-flight encryption and compression Regulatory compliance through Logical WORM and LWORM Retention support Cloud Storage Tier support for archive, logical volume versions, and disaster recovery Optional integration with physical tape 16 Gb IBM FICON® throughput that exceeds 4 GBps per TS7700 cluster Grid Resiliency Support with Control Unit Initiated Reconfiguration (CUIR) support IBM Z hosts view up to 3,968 3490 devices per TS7700 grid TS7770 Cache On Demand feature that uses capacity-based licensing TS7770 support of SSD within the VED server The TS7700T writes data by policy to physical tape through attachment to high-capacity, high-performance IBM TS1160, IBM TS1150, and IBM TS1140 tape drives that are installed in an IBM TS4500 or TS3500 tape library. The TS7770 models are based on high-performance and redundant IBM Power9® technology. They provide improved performance for most IBM Z tape workloads when compared to the previous generations of IBM TS7700.

DFSMSrmm is an IBM z/OS feature that is a fully functioning tape management system to manage your removable media. In the last decade, many enhancements were made to DFSMSrmm. This IBM Redbooks publication is intended to help you configure and use the newer functions and features that are now available. Discussion of the new features is included along with use cases. Hints and tips of various common DFSMSrmm problems and useful configuration and reporting JCL also are included. This publication is intended as a supplement to DFSMSrmm Primer, SG24-5983, which is still the recommended starting point for any users new to DFSMSrmm.

DFSMSrmm is an IBM z/OS feature that is a fully functioning tape management system to manage your removable media. In the last decade, many enhancements were made to DFSMSrmm. This IBM Redbooks publication is intended to help you configure and use the newer functions and features that are now available. Discussion of the new features is included along with use cases. Hints and tips of various common DFSMSrmm problems and useful configuration and reporting JCL also are included. This publication is intended as a supplement to DFSMSrmm Primer, SG24-5983, which is still the recommended starting point for any users new to DFSMSrmm.

This IBM® Redbooks® publication covers IBM TS7700 R5.2. The IBM TS7700 is part of a family of IBM Enterprise tape products. This book is intended for system architects and storage administrators who want to integrate their storage systems for optimal operation. Building on 25 years of experience, the R5.2 release includes many features that enable improved performance, usability, and security. Highlights include IBM TS7700 Advanced Object Store, an all flash TS7770, grid resiliency enhancements, and Logical WORM retention. By using the same hierarchical storage techniques, the TS7700 (TS7770 and TS7760) can also off load to object storage. Because object storage is cloud-based and accessible from different regions, the TS7700 Cloud Storage Tier support essentially allows the cloud to be an extension of the grid. As of this writing, the TS7700C supports the ability to off load to IBM Cloud® Object Storage, Amazon S3, and RSTOR. This publication explains features and concepts that are specific to the IBM TS7700 as of release R5.2. The R5.2 microcode level provides IBM TS7700 Cloud Storage Tier enhancements, IBM DS8000® Object Storage enhancements, Management Interface dual control security, and other smaller enhancements. The R5.2 microcode level can be installed on the IBM TS7770 and IBM TS7760 models only. Note: The latest Release 5.2 was split into two phases: R5.2 Phase 1 (also referred to as and ) R5.2 Phase 2 ( and R) TS7700 provides tape virtualization for the IBM z environment. Off loading to physical tape behind a TS7700 is used by hundreds of organizations around the world. Tape virtualization can help satisfy the following requirements in a data processing environment. New and existing capabilities of the TS7700 5.2.2 release includes the following highlights: Eight-way Grid Cloud, which consists of up to three generations of TS7700 Synchronous and asynchronous replication of virtual tape and TCT objects Grid access to all logical volume and object data that is independent of where it exists An all-flash TS7770 option for improved performance Full Advanced Object Store Grid Cloud support of DS8000 Transparent Cloud Tier Full AES256 encryption for data that is in-flight and at-rest Tight integration with IBM Z® and DFSMS policy management DS8000 Object Store AES256 in-flight encryption and compression Regulatory compliance through Logical WORM and LWORM Retention support Cloud Storage Tier support for archive, logical volume version, and disaster recovery Optional integration with physical tape 16 Gb IBM FICON® throughput that exceeds 5 GBps per TS7700 cluster Grid Resiliency Support with Control Unit Initiated Reconfiguration (CUIR) support IBM Z hosts view up to 3,968 common devices per TS7700 grid TS7770 Cache On-demand feature that is based capacity licensing TS7770 support of SSD within the VED server The TS7700T writes data by policy to physical tape through attachment to high-capacity, high-performance IBM TS1160, IBM TS1150, and IBM TS1140 tape drives that are installed in an IBM TS4500 or TS3500 tape library. The TS7770 models are based on high-performance and redundant IBM POWER9™ technology. They provide improved performance for most IBM Z tape workloads when compared to the previous generations of IBM TS7700.

The IBM® TS4500 (TS4500) tape library is a next-generation tape solution that offers higher storage density and better integrated management than previous solutions. This IBM Redbooks® publication gives you a close-up view of the new IBM TS4500 tape library. In the TS4500, IBM delivers the density that today's and tomorrow's data growth requires. It has the cost-effectiveness and the manageability to grow with business data needs, while you preserve investments in IBM tape library products. Now, you can achieve a low per-terabyte cost and high density, with up to 13 PB of data (up to 39 PB compressed) in a single 10 square-foot library by using LTO Ultrium 9 cartridges or 11 PB with 3592 cartridges. The TS4500 offers the following benefits: Support of the IBM Linear Tape-Open (LTO) Ultrium 9 tape drive: Store up to 1.04 EB 2.5:1 compressed per library with IBM LTO 9 cartridges. High availability: Dual active accessors with integrated service bays reduce inactive service space by 40%. The Elastic Capacity option can be used to eliminate inactive service space. Flexibility to grow: The TS4500 library can grow from the right side and the left side of the first L frame because models can be placed in any active position. Increased capacity: The TS4500 can grow from a single L frame up to another 17 expansion frames with a capacity of over 23,000 cartridges. High-density (HD) generation 1 frames from the TS3500 library can be redeployed in a TS4500. Capacity on demand (CoD): CoD is supported through entry-level, intermediate, and base-capacity configurations. Advanced Library Management System (ALMS): ALMS supports dynamic storage management, which enables users to create and change logical libraries and configure any drive for any logical library. Support for IBM TS1160 while also supporting TS1155, TS1150, and TS1140 tape drive. The TS1160 gives organizations an easy way to deliver fast access to data, improve security, and provide long-term retention, all at a lower cost than disk solutions. The TS1160 offers high-performance, flexible data storage with support for data encryption. Also, this enhanced fifth-generation drive can help protect investments in tape automation by offering compatibility with existing automation. Store up to 1.05 EB 3:1 compressed per library with IBM 3592 cartridges Integrated TS7700 back-end Fibre Channel (FC) switches are available. Up to four library-managed encryption (LME) key paths per logical library are available. This book describes the TS4500 components, feature codes, specifications, supported tape drives, encryption, new integrated management console (IMC), command-line interface (CLI), and REST over SCSI (RoS) to obtain status information about library components. You learn how to accomplish the following tasks: Improve storage density with increased expansion frame capacity up to 2.4 times, and support 33% more tape drives per frame

This IBM® Redbooks® publication helps you with the planning, installation, and configuration of the new IBM Spectrum® Archive Enterprise Edition (EE) Version 1.3.2.2 for the IBM TS4500, IBM TS3500, IBM TS4300, and IBM TS3310 tape libraries. IBM Spectrum Archive Enterprise Edition enables the use of the LTFS for the policy management of tape as a storage tier in an IBM Spectrum Scale based environment. It also helps encourage the use of tape as a critical tier in the storage environment. This edition of this publication is the tenth edition of IBM Spectrum Archive Installation and Configuration Guide. IBM Spectrum Archive EE can run any application that is designed for disk files on a physical tape media. IBM Spectrum Archive EE supports the IBM Linear Tape-Open (LTO) Ultrium 9, 8, 7, 6, and 5 tape drives. and the IBM TS1160, TS1155, TS1150, and TS1140 tape drives. IBM Spectrum Archive EE can play a major role in reducing the cost of storage for data that does not need the access performance of primary disk. The use of IBM Spectrum Archive EE to replace disks with physical tape in tier 2 and tier 3 storage can improve data access over other storage solutions because it improves efficiency and streamlines management for files on tape. IBM Spectrum Archive EE simplifies the use of tape by making it transparent to the user and manageable by the administrator under a single infrastructure. This publication is intended for anyone who wants to understand more about IBM Spectrum Archive EE planning and implementation. This book is suitable for IBM customers, IBM Business Partners, IBM specialist sales representatives, and technical specialists.

The IBM® TS4500 (TS4500) tape library is a next-generation tape solution that offers higher storage density and better integrated management than previous solutions. This IBM Redbooks® publication gives you a close-up view of the new IBM TS4500 tape library. In the TS4500, IBM delivers the density that today's and tomorrow's data growth requires. It has the cost-effectiveness and the manageability to grow with business data needs, while you preserve investments in IBM tape library products. Now, you can achieve a low cost per terabyte (TB) and a high TB density per square foot because the TS4500 can store up to 11 petabytes (PB) of uncompressed data in a single frame library or scale up to 2 PB per square foot to over 350 PB. The TS4500 offers the following benefits: High availability: Dual active accessors with integrated service bays reduce inactive service space by 40%. The Elastic Capacity option can be used to eliminate inactive service space. Flexibility to grow: The TS4500 library can grow from the right side and the left side of the first L frame because models can be placed in any active position. Increased capacity: The TS4500 can grow from a single L frame up to another 17 expansion frames with a capacity of over 23,000 cartridges. High-density (HD) generation 1 frames from the TS3500 library can be redeployed in a TS4500. Capacity on demand (CoD): CoD is supported through entry-level, intermediate, and base-capacity configurations. Advanced Library Management System (ALMS): ALMS supports dynamic storage management, which enables users to create and change logical libraries and configure any drive for any logical library. Support for IBM TS1160 while also supporting TS1155, TS1150, and TS1140 tape drive: The TS1160 gives organizations an easy way to deliver fast access to data, improve security, and provide long-term retention, all at a lower cost than disk solutions. The TS1160 offers high-performance, flexible data storage with support for data encryption. Also, this enhanced fifth-generation drive can help protect investments in tape automation by offering compatibility with existing automation. The TS1160 Tape Drive Model 60E delivers a dual 10 Gb or 25 Gb Ethernet host attachment interface that is optimized for cloud-based and hyperscale environments. The TS1160 Tape Drive Model 60F delivers a native data rate of 400 MBps, the same load/ready, locate speeds, and access times as the TS1155, and includes dual-port 16 Gb Fibre Channel support. Support of the IBM Linear Tape-Open (LTO) Ultrium 8 tape drive: The LTO Ultrium 8 offering represents significant improvements in capacity, performance, and reliability over the previous generation, LTO Ultrium 7, while still protecting your investment in the previous technology. Support of LTO 8 Type M cartridge (m8): The LTO Program introduced a new capability with LTO-8 drives. The ability of the LTO-8 drive to write 9 TB on a brand new LTO-7 cartridge instead of 6 TB as specified by the LTO-7 format. Such a cartridge is called an LTO-7 initialized LTO-8 Type M cartridge. Integrated TS7700 back-end Fibre Channel (FC) switches are available. Up to four library-managed encryption (LME) key paths per logical library are available. This book describes the TS4500 components, feature codes, specifications, supported tape drives, encryption, new integrated management console (IMC), command-line interface (CLI), and REST over SCSI (RoS) to obtain status information about library components. October 2020 - Added support for the 3592 model 60S tape drive that provides a dual-port 12 Gb SAS (Serial Attached SCSI) interface for host attachment.

This IBM® Redbooks® publication helps you with the planning, installation, and configuration of the new IBM Spectrum® Archive Enterprise Edition (EE) Version 1.3.1.2 for the IBM TS4500, IBM TS3500, IBM TS4300, and IBM TS3310 tape libraries. IBM Spectrum Archive Enterprise Edition enables the use of the LTFS for the policy management of tape as a storage tier in an IBM Spectrum Scale based environment. It helps encourage the use of tape as a critical tier in the storage environment. This is the ninth edition of IBM Spectrum Archive Installation and Configuration Guide. IBM Spectrum Archive EE can run any application that is designed for disk files on a physical tape media. IBM Spectrum Archive EE supports the IBM Linear Tape-Open (LTO) Ultrium 8, 7, 6, and 5 tape drives in IBM® TS3310, TS3500, TS4300, and TS4500 tape libraries. In addition, IBM TS1160, TS1155, TS1150, and TS1140 tape drives are supported in TS3500 and TS4500 tape library configurations. IBM Spectrum Archive EE can play a major role in reducing the cost of storage for data that does not need the access performance of primary disk. The use of IBM Spectrum Archive EE to replace disks with physical tape in tier 2 and tier 3 storage can improve data access over other storage solutions because it improves efficiency and streamlines management for files on tape. IBM Spectrum Archive EE simplifies the use of tape by making it transparent to the user and manageable by the administrator under a single infrastructure. This publication is intended for anyone who wants to understand more about IBM Spectrum Archive EE planning and implementation. This book is suitable for IBM customers, IBM Business Partners, IBM specialist sales representatives, and technical specialists.

This IBM® Redbooks® publication covers IBM TS7700 R5.1. The IBM TS7700 is part of a family of IBM Enterprise tape products. This book is intended for system architects and storage administrators who want to integrate their storage systems for optimal operation. Building on over 20 years of virtual tape experience, the TS7770 supports the ability to store virtual tape volumes in an object store. The TS7700 supported off loading to physical tape for over two decades. Off loading to physical tape behind a TS7700 is utilized by hundreds of organizations around the world. By using the same hierarchical storage techniques, the TS7700 (TS7770 and TS7760) can also off load to object storage. Because object storage is cloud-based and accessible from different regions, the TS7700 Cloud Storage Tier support essentially allows the cloud to be an extension of the grid. As of this writing, the TS7700C supports the ability to off load to IBM Cloud® Object Storage and Amazon S3. This publication explains features and concepts that are specific to the IBM TS7700 as of release R5.1. The R5.1 microcode level provides IBM TS7700 Cloud Storage Tier enhancements, IBM DS8000® Object Storage enhancements, Management Interface dual control security, and other smaller enhancements. The R5.1 microcode level can be installed on the IBM TS7770 and IBM TS7760 models only. TS7700 provides tape virtualization for the IBM z environment. Tape virtualization can help satisfy the following requirements in a data processing environment: Improved reliability and resiliency Reduction in the time that is needed for the backup and restore process Reduction of services downtime that is caused by physical tape drive and library outages Reduction in cost, time, and complexity by moving primary workloads to virtual tape Increased efficient procedures for managing daily batch, backup, recall, and restore processing On-premises and off-premises object store cloud storage support as an alternative to physical tape for archive and disaster recovery New and existing capabilities of the TS7700 5.1 include the following highlights: Eight-way Grid Cloud, which consists of up to three generations of TS7700 Synchronous and asynchronous replication Full AES256 encryption for replication data that is in-flight and at-rest Tight integration with IBM Z and DFSMS policy management Optional target for DS8000 Transparent Cloud Tier using DFSMS DS8000 Object Store AES256 in-flight encryption and compression Optional Cloud Storage Tier support for archive and disaster recovery 16 Gb IBM FICON® throughput up to 5 GBps per TS7700 cluster IBM Z hosts view up to 3,968 common devices per TS7700 grid Grid access to all data independent of where it exists TS7770 Cache On-demand feature that is based capacity licensing TS7770 support of SSD within the VED server The TS7700T writes data by policy to physical tape through attachment to high-capacity, high-performance IBM TS1150, and IBM TS1140 tape drives that are installed in an IBM TS4500 or TS3500 tape library. The TS7770 models are based on high-performance and redundant IBM POWER9™ technology. They provide improved performance for most IBM Z tape workloads when compared to the previous generations of IBM TS7700.

High-speed I/O workloads are moving away from the SAN to Ethernet and IBM® Spectrum Scale is pushing the network limits. The IBM Spectrum® Scale team discovered that many infrastructure Ethernet networks that were used for years to support various applications are not designed to provide a high-performance data path concurrently to many clients from many servers. IBM Spectrum Scale is not the first product to use Ethernet for storage access. Technologies, such as Fibre Channel over Ethernet (FCoE), scale out NAS, and IP connected storage (iSCSI and others) use Ethernet though IBM Spectrum Scale as the leader in parallel I/O performance, which provides the best performance and value when used on a high-performance network. This IBM Redpaper publication is based on lessons that were learned in the field by deploying IBM Spectrum Scale on Ethernet and InfiniBand networks. This IBM Redpaper® publication answers several questions, such as, "How can I prepare my network for high performance storage?", "How do I know when I am ready?", and "How can I tell what is wrong?" when deploying IBM Spectrum Scale and IBM Elastic Storage® Server (ESS). This document can help IT architects get the design correct from the beginning of the process. It also can help the IBM Spectrum Scale administrator work effectively with the networking team to quickly resolve issues.

Building on over 20 years of virtual tape experience, the TS7700 (TS7760, TS7770) now supports the ability to store virtual tape volumes in an object store. This IBM® Redpaper publication helps you set up and configure the cloud object storage support for IBM Cloud™ Object Storage (COS) or Amazon Simple Storage Service (Amazon S3). The TS7700 supported off loading to physical tape for over two decades. Off loading to physical tape behind a TS7700 is used by hundreds of organizations around the world. By using the same hierarchical storage techniques, the TS7700 can also off load to object storage. Because object storage is cloud-based and accessible from different regions, the TS7700 Cloud Storage Tier support essentially allows the cloud to be an extension of the grid. In this IBM Redpaper publication, we provide a brief overview of cloud technology with an emphasis on Object Storage. Object Storage is used by a broad set of technologies, including those technologies that are exclusive to IBM Z®. The aim of this publication is to provide a basic understanding of cloud, Object Storage, and different ways it can be integrated into your environment. This Redpaper is intended for system architects and storage administrators with TS7700 experience who want to add the support of a Cloud Storage Tier to their TS7700 solution. Note: As of this writing, the TS7700C supports the ability to offload to on-premise cloud with IBM Cloud Object Storage and public cloud with Amazon S3.

This IBM® Redbooks® publication helps you with the planning, installation, and configuration of the new IBM Spectrum® Archive v1.3.0.6 for the IBM TS4500, IBM TS3500, IBM TS4300, and IBM TS3310 tape libraries. IBM Spectrum Archive EE enables the use of the LTFS for the policy management of tape as a storage tier in an IBM Spectrum Scale based environment. It helps encourage the use of tape as a critical tier in the storage environment. This is the eighth edition of IBM Spectrum Archive Installation and Configuration Guide. IBM Spectrum Archive EE can run any application that is designed for disk files on a physical tape media. IBM Spectrum Archive EE supports the IBM Linear Tape-Open (LTO) Ultrium 8, 7, 6, and 5 tape drives in IBM TS3310, TS3500, TS4300, and TS4500 tape libraries. In addition, IBM TS1160, TS1155, TS1150, and TS1140 tape drives are supported in TS3500 and TS4500 tape library configurations. IBM Spectrum Archive EE can play a major role in reducing the cost of storage for data that does not need the access performance of primary disk. The use of IBM Spectrum Archive EE to replace disks with physical tape in tier 2 and tier 3 storage can improve data access over other storage solutions because it improves efficiency and streamlines management for files on tape. IBM Spectrum Archive EE simplifies the use of tape by making it transparent to the user and manageable by the administrator under a single infrastructure. This publication is intended for anyone who wants to understand more about IBM Spectrum Archive EE planning and implementation. This book is suitable for IBM clients, IBM Business Partners, IBM specialist sales representatives, and technical specialists.

The IBM® TS4500 (TS4500) tape library is a next-generation tape solution that offers higher storage density and integrated management than previous solutions. This IBM Redbooks® publication gives you a close-up view of the new IBM TS4500 tape library. In the TS4500, IBM delivers the density that today's and tomorrow's data growth requires. It has the cost-effectiveness and the manageability to grow with business data needs, while you preserve existing investments in IBM tape library products. Now, you can achieve both a low cost per terabyte (TB) and a high TB density per square foot because the TS4500 can store up to 11 petabytes (PB) of uncompressed data in a single frame library or scale up to 2 PB per square foot to over 350 PB. The TS4500 offers the following benefits: High availability: Dual active accessors with integrated service bays reduce inactive service space by 40%. The Elastic Capacity option can be used to completely eliminate inactive service space. Flexibility to grow: The TS4500 library can grow from the right side and the left side of the first L frame because models can be placed in any active position. Increased capacity: The TS4500 can grow from a single L frame up to another 17 expansion frames with a capacity of over 23,000 cartridges. High-density (HD) generation 1 frames from the TS3500 library can be redeployed in a TS4500. Capacity on demand (CoD): CoD is supported through entry-level, intermediate, and base-capacity configurations. Advanced Library Management System (ALMS): ALMS supports dynamic storage management, which enables users to create and change logical libraries and configure any drive for any logical library. Support for IBM TS1160 while also supporting TS1155, TS1150, and TS1140 tape drive: The TS1160 gives organizations an easy way to deliver fast access to data, improve security, and provide long-term retention, all at a lower cost than disk solutions. The TS1160 offers high-performance, flexible data storage with support for data encryption. Also, this enhanced fifth-generation drive can help protect investments in tape automation by offering compatibility with existing automation. The TS1160 Tape Drive Model 60E delivers a dual 10 Gb or 25 Gb Ethernet host attachment interface that is optimized for cloud-based and hyperscale environments. The TS1160 Tape Drive Model 60F delivers a native data rate of 400 MBps, the same load/ready, locate speeds, and access times as the TS1155, and includes dual-port 16 Gb Fibre Channel support. Support of the IBM Linear Tape-Open (LTO) Ultrium 8 tape drive: The LTO Ultrium 8 offering represents significant improvements in capacity, performance, and reliability over the previous generation, LTO Ultrium 7, while still protecting your investment in the previous technology. Support of LTO 8 Type M cartridge (M8): The LTO Program is introducing a new capability with LTO-8 drives. The ability of the LTO-8 drive to write 9 TB on a brand new LTO-7 cartridge instead of 6 TB as specified by the LTO-7 format. Such a cartridge is called an LTO-7 initialized LTO-8 Type M cartridge. Integrated TS7700 back-end Fibre Channel (FC) switches are available. Up to four library-managed encryption (LME) key paths per logical library are available. This book describes the TS4500 components, feature codes, specifications, supported tape drives, encryption, new integrated management console (IMC), command-line interface (CLI), and REST over SCSI (RoS) to obtain status information about library components. You learn how to accomplish the following specific tasks:: Improve storage density with increased expansion frame capacity up to 2.4 times and support 33% more tape drives per frame

This IBM® Redpaper publication provides a comprehensive overview of the IBM Spectrum® Discover metadata management software platform. We give a detailed explanation of how the product creates, collects, and analyzes metadata. Several in-depth use cases are used that show examples of analytics, governance, and optimization. We also provide step-by-step information to install and set up the IBM Spectrum Discover trial environment. More than 80% of all data that is collected by organizations is not in a standard relational database. Instead, it is trapped in unstructured documents, social media posts, machine logs, and so on. Many organizations face significant challenges to manage this deluge of unstructured data such as: Pinpointing and activating relevant data for large-scale analytics Lacking the fine-grained visibility that is needed to map data to business priorities Removing redundant, obsolete, and trivial (ROT) data Identifying and classifying sensitive data IBM Spectrum Discover is a modern metadata management software that provides data insight for petabyte-scale file and Object Storage, storage on premises, and in the cloud. This software enables organizations to make better business decisions and gain and maintain a competitive advantage. IBM Spectrum Discover provides a rich metadata layer that enables storage administrators, data stewards, and data scientists to efficiently manage, classify, and gain insights from massive amounts of unstructured data. It improves storage economics, helps mitigate risk, and accelerates large-scale analytics to create competitive advantage and speed critical research.

Note: This is a republication of IBM Spectrum Archive Enterprise Edition V1.2.6: Installation and Configuration Guide with new book number SG24-8445 to keep the content available on the Internet along with the recent publication IBM Spectrum Archive Enterprise Edition V1.3.0: Installation and Configuration Guide, SG24-8333. This IBM® Redbooks® publication helps you with the planning, installation, and configuration of the new IBM Spectrum™ Archive V1.2.6 for the IBM TS3310, IBM TS3500, IBM TS4300, and IBM TS4500 tape libraries. IBM Spectrum Archive™ EE enables the use of the LTFS for the policy management of tape as a storage tier in an IBM Spectrum Scale™ based environment. It helps encourage the use of tape as a critical tier in the storage environment. This is the sixth edition of IBM Spectrum Archive Installation and Configuration Guide. IBM Spectrum Archive EE can run any application that is designed for disk files on a physical tape media. IBM Spectrum Archive EE supports the IBM Linear Tape-Open (LTO) Ultrium 8, 7, 6, and 5 tape drives in IBM TS3310, TS3500, TS4300, and TS4500 tape libraries. In addition, IBM TS1155, TS1150, and TS1140 tape drives are supported in TS3500 and TS4500 tape library configurations. IBM Spectrum Archive EE can play a major role in reducing the cost of storage for data that does not need the access performance of primary disk. The use of IBM Spectrum Archive EE to replace disks with physical tape in tier 2 and tier 3 storage can improve data access over other storage solutions because it improves efficiency and streamlines management for files on tape. IBM Spectrum Archive EE simplifies the use of tape by making it transparent to the user and manageable by the administrator under a single infrastructure. This publication is intended for anyone who wants to understand more about IBM Spectrum Archive EE planning and implementation. This book is suitable for IBM clients, IBM Business Partners, IBM specialist sales representatives, and technical specialists.

This IBM® Redbooks® publication covers IBM TS7700 R4.2. The IBM TS7700 is part of a family of IBM Enterprise tape products. This book is intended for system architects and storage administrators who want to integrate their storage systems for optimal operation. Building on over 20 years of virtual tape experience, the TS7760 now supports the ability to store virtual tape volumes in an object store. The TS7700 has supported off loading to physical tape for over two decades. Off loading to physical tape behind a TS7700 is utilized by hundreds of organizations around the world. Using the same hierarchical storage techniques, the TS7700 can also off load to object storage. Given object storage is cloud based and accessible from different regions, the TS7760 Cloud Storage Tier support essentially allows the cloud to be an extension of the grid. As of the release of this document, the TS7760C supports the ability to off load to IBM Cloud Object Storage as well as Amazon S3. To learn about the TS7760 cloud storage tier function, planning, implementation, best practices, and support see IBM Redpaper IBM TS7760 R4.2 Cloud Storage Tier Guide, redp-5514 at: http://www.redbooks.ibm.com/abstracts/redp5514.html The IBM TS7700 offers a modular, scalable, and high-performance architecture for mainframe tape virtualization for the IBM Z® environment. It is a fully integrated, tiered storage hierarchy of disk and tape. This storage hierarchy is managed by robust storage management microcode with extensive self-management capability. It includes the following advanced functions: Improved reliability and resiliency Reduction in the time that is needed for the backup and restore process Reduction of services downtime that is caused by physical tape drive and library outages Reduction in cost, time, and complexity by moving primary workloads to virtual tape More efficient procedures for managing daily backup and restore processing Infrastructure simplification through reduction of the number of physical tape libraries, drives, and media TS7700 delivers the following new capabilities: TS7760C supports the ability to off load to IBM Cloud Object Storage as well as Amazon S3 8-way Grid Cloud consisting of any generation of TS7700 Synchronous and asynchronous replication Tight integration with IBM Z and DFSMS policy management Optional Transparent Cloud Tiering Optional integration with physical tape Cumulative 16Gb FICON throughput up to 4.8GB/s 8 IBM Z hosts view up to 496 8 equivalent devices Grid access to all data independent of where it exists The TS7760T writes data by policy to physical tape through attachment to high-capacity, high-performance IBM TS1150 and IBM TS1140 tape drives installed in an IBM TS4500 or TS3500 tape library. The TS7760 models are based on high-performance and redundant IBM POWER8® technology. They provide improved performance for most IBM Z tape workloads when compared to the previous generations of IBM TS7700.

This IBM® Redbooks® publication helps you with the planning, installation, and configuration of the new IBM Spectrum™ Archive Enterprise Edition v1.3.0 for the IBM TS3310, IBM TS3500, IBM TS4300, and IBM TS4500 tape libraries. IBM Spectrum Archive™ EE enables the use of LTFS for the policy management of tape as a storage tier in an IBM Spectrum Scale™ based environment. It helps encourage the use of tape as a critical tier in the storage environment. This is the seventh edition of IBM Spectrum Archive Installation and Configuration Guide. IBM Spectrum Archive EE can run any application that is designed for disk files on a physical tape media. IBM Spectrum Archive EE supports the IBM Linear Tape-Open (LTO) Ultrium 8, 7, 6, and 5 tape drives in IBM TS3310, TS3500, TS4300, and TS4500 tape libraries. In addition, IBM TS1160, TS1155, TS1150, and TS1140 tape drives are supported in TS3500 and TS4500 tape library configurations. IBM Spectrum Archive EE can play a major role in reducing the cost of storage for data that does not need the access performance of primary disk. The use of IBM Spectrum Archive EE to replace disks with physical tape in tier 2 and tier 3 storage can improve data access over other storage solutions because it improves efficiency and streamlines management for files on tape. IBM Spectrum Archive EE simplifies the use of tape by making it transparent to the user and manageable by the administrator under a single infrastructure. This publication is intended for anyone who wants to understand more about IBM Spectrum Archive EE planning and implementation. This book is suitable for IBM clients, IBM Business Partners, IBM specialist sales representatives, and technical specialists.

Storage systems must provide reliable and convenient data access to all authorized users while simultaneously preventing threats coming from outside or even inside the enterprise. Security threats come in many forms, from unauthorized access to data, data tampering, denial of service, and obtaining privileged access to systems. According to the Storage Network Industry Association (SNIA), data security in the context of storage systems is responsible for safeguarding the data against theft, prevention of unauthorized disclosure of data, prevention of data tampering, and accidental corruption. This process ensures accountability, authenticity, business continuity, and regulatory compliance. Security for storage systems can be classified as follows: Data storage (data at rest, which includes data durability and immutability) Access to data Movement of data (data in flight) Management of data IBM® Spectrum Scale is a software-defined storage system for high performance, large-scale workloads on-premises or in the cloud. IBM Spectrum™ Scale addresses all four aspects of security by securing data at rest (protecting data at rest with snapshots, and backups and immutability features) and securing data in flight (providing secure management of data, and secure access to data by using authentication and authorization across multiple supported access protocols). These protocols include POSIX, NFS, SMB, Hadoop, and Object (REST). For automated data management, it is equipped with powerful information lifecycle management (ILM) tools that can help administer unstructured data by providing the correct security for the correct data. This IBM Redpaper™ publication details the various aspects of security in IBM Spectrum Scale™, including the following items: Security of data in transit Security of data at rest Authentication Authorization Hadoop security Immutability Secure administration Audit logging Security for transparent cloud tiering (TCT) Security for OpenStack drivers Unless stated otherwise, the functions that are mentioned in this paper are available in IBM Spectrum Scale V4.2.1 or later releases.

Today, new business models in the marketplace coexist with traditional ones and their well-established IT architectures. They generate new business needs and new IT requirements that can only be satisfied by new service models and new technological approaches. These changes are reshaping traditional IT concepts. Cloud in its three main variants (Public, Hybrid, and Private) represents the major and most viable answer to those IT requirements, and software-defined infrastructure (SDI) is its major technological enabler. IBM® technology, with its rich and complete set of storage hardware and software products, supports SDI both in an open standard framework and in other vendors' environments. IBM services are able to deliver solutions to the customers with their extensive knowledge of the topic and the experiences gained in partnership with clients. This IBM Redpaper™ publication focuses on software-defined storage (SDS) and IBM Storage Systems product offerings for software-defined environments (SDEs). It also provides use case examples across various industries that cover different client needs, proposed solutions, and results. This paper can help you to understand current organizational capabilities and challenges, and to identify specific business objectives to be achieved by implementing an SDS solution in your enterprise.

This IBM® Redpaper™ publication provides guidance on building an enterprise-grade data lake by using IBM Spectrum™ Scale and Hortonworks Data Platform for performing in-place Hadoop or Spark-based analytics. It covers the benefits of the integrated solution, and gives guidance about the types of deployment models and considerations during the implementation of these models. Hortonworks Data Platform (HDP) is a leading Hadoop and Spark distribution. HDP addresses the complete needs of data-at-rest, powers real-time customer applications, and delivers robust analytics that accelerate decision making and innovation. IBM Spectrum Scale™ is flexible and scalable software-defined file storage for analytics workloads. Enterprises around the globe have deployed IBM Spectrum Scale to form large data lakes and content repositories to perform high-performance computing (HPC) and analytics workloads. It can scale performance and capacity both without bottlenecks.
